Every so often, I come across data that makes me pause. Recently, while reading a Technical Bulletin, I encountered a simple graph showing bacterial population increases in an aquifer following product application. The graph was offered as a “line of evidence” supporting the product’s effectiveness (CAC, 2023).

However, when I examined the microbial counts, my initial thought was: Those numbers are ordinary.

To put things in context, I overlaid microbial count data from a site in Tennessee treated with a single application of RPI’s BOS 200+ onto the same graph. (See Graph 1.) For each quarter, the first two columns show the competitor’s data from Indiana; the second two show BOS 200+ data from Tennessee. Naturally, the sites differ in location and characteristics, and a variety of factors could influence the outcomes. Still, assuming the competitor is putting their best foot forward, the comparison seems fair.

At both sites, baseline microbial counts hover around 10⁶ cells/mL—a typical background level for the eastern United States. In petroleum-impacted groundwater, concentrations of 10⁷ cells/mL are often observed. A robust biostimulation effort should increase microbial populations 10 to 100 times above the impacted baseline. See, for example, Figure 16.11 (Noland and Winner, 2024). A jump from 10⁶ to over 10⁸ cells/mL is a reasonable benchmark for success in the Eastern U.S.

In that light, an increase from 10⁶ to 10⁷ isn’t exactly headline-worthy; it could just reflect natural variation in plume characteristics. On the other hand, the BOS 200+ data show microbial counts exceeding 10⁹ cells/mL by the second quarter post-application, levels that are then sustained for the duration of sampling.

That’s the kind of result that deserves attention.

So, yes—file this under: Things that make you go, Hmmm…

References

CAC, T.B. (2023). regenesis.com/wp-content/uploads/2019/12/Technical-Bulletin-Biodegradation-of-Contaminants-on-CAC-1-23-23-1.pdf Retrieved June 14, 2025.

Noland and Winner (2024). Activated Carbon Injection for In-Situ Remediation of Petroleum Hydrocarbons. In E. G. J. Garcia-Rincon, Advances in the Characterization and Remediation of Sites Contaminated with Petroleum Hydrocarbons (pp. 549-589). Cham, Switzerland: Springer.

Graph 1. Moving from left to right, the salmon and green columns are from a competitor’s Technical Bulletin. The burgundy and purple columns display bacterial count data after BOS 200+ treatment. The BOS 200+ data is 100-fold higher than that in the Technical Bulletin.
